Marine Containerized ESS
Certification issued by CCS
Standard 20-ft battery containers
Marine Containerized ESS
It is suitable for both pure battery-powered and hybrid-powered ships, and can be used as the ship’s propulsion power supply, main power supply, emergency power supply, standby power supply, and starting power supply. It serves functions such as peak shaving, spinning reserve, and dynamic performance enhancement. It can be installed on the deck without requiring extensive modifications to the engine room structure, making it ideal for ship retrofitting projects.
Technical Specifications
| Nominal Voltage (V) | 772.8 |
| Voltage Range (V) | 600~876 |
| Nominal Energy (kWh) | 1959.82 |
| Operating Temperature | Charge: 0℃~55℃ | Discharge: -10℃~65℃ |
| Maximum continuous charge-discharge rate | 0.5C |
| Class Compliance | CCS |
| Size (L*W*H) | 6058 *2438 *2896 mm(ISO 1CCC type 20-foot container) |
| Cooling Method | Liquid |
| Fire Protection System | Heptafluoropropane and fire alarm system |
| Fire rating | A60(battery compartment area) |
